• Bright rear bumper
• Front air dam
• Bright grille
• Body-color/bright front fascia
• Chrome body-side molding
• Halogen headlamps
• Fog lamps
• Fold away pwr heated mirrors
• Tinted glass
• Variable speed intermittent windshield wipers
• Cargo lamp

• Leather trim 40/20/40 bench seat
• 6-way pwr driver seat
• Rear 60/40 split bench seat
• Front center seat cushion storage
• Mini floor console
• Carpeted floor covering
• Floor tunnel insulation
• Leather-wrapped steering wheel
• Tilt steering column
• Sentry Key theft deterrent system
• Tip start
• Instrument cluster-inc: 120 MPH primary speedometer, tachometer
• Bright interior accents
• Pwr adjustable pedals
• Pwr windows w/driver one-touch down
• Pwr locks
• Remote keyless entry
• Pwr accessory delay
• Speed control
• Security alarm
• Air conditioning w/dual zone temp control
• AM/FM stereo w/CD player-inc: (4) speakers, aux input jack
• Sirius satellite radio w/1-year service *N/A in AK or HI*
• Fixed long mast antenna
• 12V pwr outlet
• Cigar lighter
• Woodgrain instrument panel bezel
• Auto dimming rearview mirror
• Overhead console w/trip computer
• Passenger assist handle
• Dual illuminated visor vanity mirrors
• Front dome light w/on-off switch lamp
• Ash tray lamp
• Glove box lamp
• Underhood lamp
• Rear underseat compartment storage
• Flat folding load floor storage

• Pwr 4-wheel anti-lock disc brakes
• "Next Generation" front airbags
• Front height adjustable shoulder belts
• Dual note horn

2UH LARAMIE CUSTOMER PREFERRED ORDER SELECTION PKG

• 5.9L I6 HO turbo diesel engine
• 48RE 4-speed auto trans
• 17" x 8" aluminum chrome clad wheels
• (7) infinity speakers
• AM/FM/MP3 stereo w/6-disc in-dash CD changer
• overhead console w/trip computer & universal garage door opener
• steering wheel mounted audio controls
• electronic shift-on-the-fly transfer case
• heated front seats
• pwr 6-way driver/passenger seat
• pwr sliding rear window

PROTECTION GROUP

• transfer case skid plate
• tow hooks

TRAILER TOW GROUP

• Class IV trailer hitch receiver
• 7-pin wiring harness
• 750-amp maintenance-free battery

4-SPEED AUTOMATIC TRANSMISSION W/OD

• aux transmission oil cooler

5.9L (360) HO I6 CUMMINS TURBO DIESEL ENGINE

• 750-amp maintenance-free battery
• 9000# GVWR
• tow hooks

3.73 AXLE RATIO

• (STD)

AM/FM/MP3 STEREO W/6-DISC IN-DASH CD CHANGER, GPS NAVIGATION SYSTEM

• (7) Infinity speakers
• 5.8" screen

UCONNECT HANDS-FREE COMMUNICATION

• auto dimming rearview mirror

LT265/70R17E ALL-SEASON BSW TIRES

• (STD)

• 3.73 Axle Ratio
• Rear Anti-Spin Differential Axle
• 17" x 8" Chrome Clad Steel Wheels
• 17" x 8" Chrome Clad Aluminum Wheels
• Leather Trim 40/20/40 Bench Seat
• Heated Front Seats
• AM/FM Compact Disc
• 6CD/Full Map GPS Display Navigation
• Folding Flat Load Floor Storage
• Front & Rear Floor Mats
• Front Hood Protection Shield
• Power Fold-Away Trailer Tow Mirrors
• Protection Group
• Front/Rear Supplemental Side Curtain Airbags
• Trailer Tow Group
• Uconnect Hands-Free Communication
• 750 Amp Maintenance Free Battery
• Transfer Case Skid Plate Shield
• Rear 60/40 Split Folding Seat
• Front Center Seat Cushion Storage
• Hood Insulation
• Auxiliary Transmission Oil Cooler
• Electronically Controlled Throttle
• Tow Hooks
• Class IV Receiver Hitch
• 7 Pin Wiring Harness
• 4 Speakers
• AM/FM radio: SIRIUS
• Front Center Armrest w/Storage
• Compass
• Speed-Sensitive Wipers
• Auto-dimming Rear-View mirror
• Front beverage holders
• Variably intermittent wipers
• Trip computer
• Tilt steering wheel
• Split folding rear seat
• Speed control
• Security system
• Remote keyless entry
• Rear step bumper
• Power windows
• Power steering
• Power driver seat
• Power door mirrors
• Passenger vanity mirror
• Passenger door bin
• Panic alarm
• Overhead console
• Outside temperature display
• Leather steering wheel
• Illuminated entry
• Heated door mirrors
• Front reading lights
• Front fog lights
• Front dual zone A/C
• Front anti-roll bar
• Dual front impact airbags
• Driver vanity mirror
• Driver door bin
• Delay-off headlights
• CD player
• Bumpers: body-color
• Bodyside moldings
• Adjustable pedals
• ABS brakes
• Voltmeter
• Tachometer
• Air Conditioning
• 4-Wheel Disc Brakes

• Electrical
• Cold Cranking Amps @ 0° F (Primary): 750
• Cold Cranking Amps @ 0° F (Primary): 600
• Maximum Alternator Capacity (amps): 136
• Maximum Alternator Watts: 1904
• Cooling System
• Total Cooling System Capacity (qts): 32.7
• Total Cooling System Capacity (qts): 18.7
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 5200
• Gross Axle Wt Rating - Rear (lbs): 6010
• Curb Weight - Front (lbs): 4458
• Curb Weight - Front (lbs): 3746
• Curb Weight - Rear (lbs): 2736
• Curb Weight - Rear (lbs): 2661
• Gross Vehicle Weight Rating Cap (lbs): 9000
• Gross Vehicle Weight Rating Cap (lbs): 8800
• Gross Combined Wt Rating (lbs): 20000
• Gross Combined Wt Rating (lbs): 15000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 12650
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 8450
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1265
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 845
• Suspension
• Suspension Type - Front: Coil
• Suspension Type - Rear: Leaf
• Axle Type - Front: Hypoid
• Axle Type - Rear: Full-floating
• Axle Capacity - Front (lbs): 4750
• Axle Capacity - Front (lbs): 4000
• Axle Capacity - Rear (lbs): 6150
• Axle Ratio (:1) - Front: 3.73
• Axle Ratio (:1) - Rear: 3.73
• Shock Absorber Diameter - Front (mm): - TBD -
• Shock Absorber Diameter - Rear (mm): - TBD -
• Stabilizer Bar Diameter - Front (in): - TBD -
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 13.9 x 1.26
• Rear Brake Rotor Diam x Thickness (in): 13.9 x 1.18
• Tires
• Front Tire Order Code: TT3
• Rear Tire Order Code: TT3
• Spare Tire Order Code: TBB
• Front Tire Size: LT265/70R17E
• Rear Tire Size: LT265/70R17E
• Spare Tire Size: LT265/70R17E
• Front Tire Capacity (lbs): 3190
• Rear Tire Capacity (lbs): 3190
• Spare Tire Capacity (lbs): - TBD -
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 17 x 8.0
• Rear Wheel Size (in): 17 x 8.0
• Spare Wheel Size (in): 17 x 8.0
• Front Wheel Material: Aluminum
• Front Wheel Material: Steel
• Rear Wheel Material: Aluminum
• Rear Wheel Material: Steel
• Spare Wheel Material: Aluminum
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr Rack & Pinion
• Steering Ratio (:1), On Center: - TBD -
• Steering Ratio (:1), At Lock: - TBD -
• Turning Diameter - Curb to Curb (ft): 50.3
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 35
• Fuel Tank Location: Inboard Frame Rails
• Exterior Dimensions
• Wheelbase (in): 160.5
• Length, Overall w/o rear bumper (in): 249.7
• Width, Max w/o mirrors (in): 79.9
• Height, Overall (in): 78.5
• Overhang, Front (in): 39.4
• Overhang, Rear w/o bumper (in): 49.9
• Front Bumper to Back of Cab (in): - TBD -
• Cab to Axle (in): - TBD -
• Cab to End of Frame (in): - TBD -
• Ground to Top of Load Floor (in): 36.2
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): - TBD -
• Ground Clearance, Front (in): 12.9
• Ground Clearance, Rear (in): 7.1
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 98.3
• Cargo Box Width @ Top, Rear (in): - TBD -
• Cargo Box Width @ Floor (in): 66.4
• Cargo Box Width @ Wheelhousings (in): 51.0
• Cargo Box (Area) Height (in): 20.2
• Tailgate Width (in): 60.6
• Cargo Volume (ft³): 74.9
• Ext'd Cab Cargo Volume (ft³): 56.7
• Interior Dimensions
• Passenger Capacity: 6
• Front Head Room (in): 40.2
• Front Leg Room (in): 41.0
• Front Shoulder Room (in): 67.0
• Front Hip Room (in): 65.1
• Second Head Room (in): 40.0
• Second Leg Room (in): 36.4
• Second Shoulder Room (in): 66.7
• Second Hip Room (in): 64.6
• Summary
• Vehicle Name: Dodge Ram 2500
• Body Style: Quad Cab 8' Box
• Body Code: 160.5" WB
